TOYO东洋光通信器SOT-NP401S光通信设备刘15621198049

货号: #SOT-NP401S

库存: 25

品牌:

¥2490.00 ¥1200.00

简介

TOYO东洋光通信器SOT-NP401S光通信设备刘15621198049

分类: 工控传动,

产品详情

TOYO东洋光通信器SOT-NP401S光通信设备刘15621198049TOYO东洋光通信器SOT-NP401S光通信设备刘15621198049TOYO东洋光通信器SOT-NP401S光通信设备刘15621198049TOYO东洋光通信器SOT-NP401S光通信设备刘15621198049TOYO东洋光通信器SOT-NP401S光通信设备刘15621198049

Specifications

Model	SOT-NP401H/S□	SOT-NP403H/S□	SOT-NP801H/S□	SOT-NP803H/S□
Rated power voltage	DC12/24V Ripple 100 mVp-p or less
Power voltage used	DC10 – 30V Ripple 100 mVp-p or less
Consumable current	60mA MAX
Transmission distance	0 – 1m	0.1 – 3m	0 – 1m	0.1 – 3m
Direction angle	30°	5°	30°	5°
Transmitting points	Input 4-bit/Output 4-bit		Input 8-bit/Output 8-bit
Transmission method	Half-duplex 2-way and 1-way direction
Detecting method	Bit reverse any time comparison method
Transmitting time	15ms MAX (M/S mode) 20ms MAX (X mode)
Projecting element	Short-wave-length infrared LED
Receiving element	Photo transistor
Modulation method	Pulse modulation 45 KHz
