TOYO东洋光通信器SOT-NP401S光通信设备青岛平山郭-158-54210565
产品详情
TOYO东洋光通信器SOT-NP401S光通信设备青岛平山郭-158-54210565
TOYO东洋光通信器SOT-NP401S光通信设备青岛平山郭-158-54210565
TOYO东洋光通信器SOT-NP401S光通信设备青岛平山郭-158-54210565
Specifications
Model | SOT-NP401H/S□ | SOT-NP403H/S□ | SOT-NP801H/S□ | SOT-NP803H/S□ |
Rated power voltage | DC12/24V Ripple 100 mVp-p or less | |||
Power voltage used | DC10 – 30V Ripple 100 mVp-p or less | |||
Consumable current | 60mA MAX | |||
Transmission distance | 0 – 1m | 0.1 – 3m | 0 – 1m | 0.1 – 3m |
Direction angle | 30° | 5° | 30° | 5° |
Transmitting points | Input 4-bit/Output 4-bit | Input 8-bit/Output 8-bit | ||
Transmission method | Half-duplex 2-way and 1-way direction | |||
Detecting method | Bit reverse any time comparison method | |||
Transmitting time | 15ms MAX (M/S mode) 20ms MAX (X mode) | |||
Projecting element | Short-wave-length infrared LED | |||
Receiving element | Photo transistor | |||
Modulation method | Pulse modulation 45 KHz | |||
¥1170.00
