Magnescale索尼探规位移传感器DK812SBVR5青岛平山技研刘15621198049
产品详情
Magnescale索尼探规位移传感器DK812SBVR5青岛平山技研刘15621198049
Specifications
| Specifications | ||
|---|---|---|
*1 Values in parentheses show those of type B. *2 Excluding the interpolation box and connector *3 When Φ4 mm tube is used in the right angle type *4 Excluding interpolation box and connector *5 There are some differences in the shape and dimensions from the previous DK800 series models. Magnescale reserves the right to change product specifications without prior notice. | ||
| Model | High resolution model | General purpose resolution model |
| DK805SAR, DK805SALR, DK805SAFR, DK805SAFLR, DK805SBR, DK805SBLR, DK805SBFR, DK805SBFLR | DK805SAR5, DK805SALR5, DK805SAFR5, DK805SAFLR5, DK805SBR5, DK805SBLR5, DK805SBFR5, DK805SBFLR5 | |
| Measuring range | 5 mm | |
| Maximum resolution | 0.1 µm | 0.5 µm |
| Accuracy (at 20 °C) | 1 µm p-p | 1.5 µm p-p |
| Measuring force (at 20 °C) | Upward: 0.35 ±0.25 N | |
| Horizontal: 0.40 ±0.25 N | ||
| Downward: 0.45 ±0.25 N | ||
| Operating temperature | 0 to +50 °C (no condensation) | |
| Storage temperature | -20 to +60 °C (90 %RH or less) | |
| Maximum response speed *1 | 80 m/min (42 m/min) | 250 m/min (100 m/min) |
| Spindle driving | Spring push (All model) Air drive by vacuum suction is possible (DK805S*LR*) | |
| Reference point response speed | Same as maximum response speed noted above | |
| Reference point | at 1 mm ±0.5 mm position of spindle movement | |
| Protection grade *2 | Straight type: IP67 / Right angle type: IP64 (IP67*3 ) | |
| Vibration resistance | 100 m/s2 (20 to 2,000 Hz) | |
| Impact resistance | 1,000 m/s2 (11 ms) | |
| Power supply | DC 5 V ±5 % | |
| Power consumption | 1 W | |
| Output | A/B/reference point, voltage-differential line driver output (conforming to EIA-422) | |
| Mass*4 | Approx. 30 g | |
| Feeler | Carbide ball tip, mounting screw M2.5 | Steel ball tip, mounting screw M2.5 |
| Output cable length | 2.5 m | |
| Accessories | Instruction manual, +P M4 x 5 screws (2 pc), tightening nut, clamp spanner, wave washer, mounting pins 1 each (for DK8**S*F** only), hose elbow (for DK8**S*L** only), spanner, supplement | |
