日本进口OPTEX测距仪面积计算器CVSE1-N20-RA青岛平山郭15854210565

测量工具类日本进口OPTEX测距仪面积计算器CVSE1-N20-RA青岛平山郭15854210565

货号: #CVSE1-N20-RA

库存: 13

品牌:

¥5655.00 ¥3240.00

日本进口OPTEX测距仪面积计算器CVSE1-N20-RA青岛平山郭15854210565

分类: 测量工具类,

产品详情

日本进口OPTEX测距仪面积计算器CVSE1-N20-RA青岛平山郭15854210565

任何人都可以使用的简单操作
色彩辨别图像传感器

用途用于图像检查目的，例如检查是否存在贴纸。种类图像传感器

Model	CVSE1-N10-RA	CVSE1-N20-RA	CVSE1-N21-RA	CVSE1-N40-RA
Model	CVSE1-P10-RA	CVSE1-P20-RA	CVSE1-P21-RA	CVSE1-P40-RA
Detection angle	10°	20°		40°
Working distance	210 to 270mm	90 to 150mm	31 to 39mm	50 to 100mm
Field of view	40 x 50mm to 55 x 65mm	40 x 50mm to 65 x 75mm	17 x 20mm (±10%)	50 x 65mm to 100 x 115mm
Light source	White LED 12 pcs built-in
Image sensor	330,000 Pixel CMOS color image sensor
Supply Voltage	12 to 24V DC±10%
Power consumption	Max. 120mA/24V DC
Resolution	5 x12 to 200 x 240
LED light duration	Approx.50,000 hours (In normal temperature and humidity. Brightness level down by 1/2 of the initial level)
Response time	2.8ms to 27.9ms. Factory setting:27.9ms when SYNCHRO=HIGH, BRIGHT=100, RESOLUT=NORM
Output	NPN or PNP open collector output x 1 max.100mA Residual voltage 1.0V or less
Input	Bank select 0 to 3, Sync input
Operating temperature	0 to 40℃ (No condensation)
Operating humidity	35 to 85%RH
Storage temperature/humidity	-20 to 70℃,35 to 95%RH (No condensation)
Vibration/shock resistance	10 to 55Hz Amplitude 1.5mm/50G (500m/s2)
Material	Case:ABS/Display and Lens : Acryl or Polycarbonate
Protection structure	IP67
Weight	Approx.200g (including cable)
