SHOWA正和行进式系统用分配器SG610B青岛平山郭-158-54210565

环境设备类 SHOWA正和行进式系统用分配器SG610B青岛平山郭-158-54210565

SHOWA正和行进式系统用分配器SG610B青岛平山郭-158-54210565

货号: #SG610B

库存: 11

品牌:

¥8470.00 ¥4960.00

简介

SHOWA正和行进式系统用分配器SG610B青岛平山

分类: 环境设备类,

产品详情

SHOWA正和行进式系统用分配器SG610B青岛平山

联系人郭经理 15854210565

Specifications

MODEL CODE	Number of Outlets	Discharge Volume Per Port	Connection Sizes	Max. Operating Pressure (Mpa)	Applicable Grease
SG604	4	0.3㎥/st Can be increased using a PSG attachment	Supply Port Rc¹/₈ Outlet M10 × 1.0	14	NLGI No.00～1
SG606	6
SG608	8
SG610	10
SG612	12

※The SG unit will not operate if any distribution port(outlet) is sealed. Use a PSG or install a return line to the grease pump.

※A single port will discharge 0.3c㎥/st. APSG attachment can be used to combine multiple discharge ports into a single outlet.

※E.g. A PSG102 will combine 2 ports enabling 0.6c㎥/st of grease to be delivered to a single point, while using a PSG104 to combine 4 ports will allow 1.2c㎥/st of grease to be delivered to a single lubrication point.

产品规格

形式	释放字数	吐出量	最高使用率压力	连接直径		适用润滑脂一致性（NLGI）
				供应口	吐出口
SG604※	4	0.3c㎥/st 附件可以增加	14兆帕	遥控¹ / ₈	M10×1.0	#000～#1
